semi-electric stacker

Semi-electric stacker is an economical choice for a variety of basic material handling needs,which is a half electric forklift for load and unload and short-distance transportation. There is no noise and pollution.The malfunction rate is low. Lift function is electro hydraulic while movement is manual,suitable for all your lifting needs(racking,shelving, unloading etc).Compact design with strong steel construction. Equipped with wheels in the mast also allows it to be used as trolley.Light and esay manual steering system with effortless pulling during transport with long tiller.

Product features

Simple and convenient operation system
integrated charger facilitates easy and reliable charging.
Safe packing in any situation with mechanical parking brake.
Precise lifting and lowering via hand lever.
Easy to maneuver Compulsively controlled wheel ensures good precise maneuvering..
Trouble free power pack Simple,reliable hydraulics providing access to facilitate service of pump and battery.
Easy operation Ergonomically designed steering handle reduces pulling power and minimises operator fatigue.
Enhanced safety Foot operated mechanical parking brake ensures safe parking in any situation.
HYDRAULIC SYSTEM; The battery operated pump is mounted; directly on the hydraulic tank.The lifting and lowering functions are controlled by a valve with built-in over pressure function,which prevents overload.
A lowering brake valve ensures that the maximum lowering speed is not exceeded at full load.
Material code   unit
Drive form     Semi-electric Semi-electric
Driving style     Pedestrian Pedestrian
Rated load Q kg 1000 1500 1000/1500
Load center C mm 500 500
Total lenggy 1t mm 1674 1674
  1.5t mm 1691 1691
Overall width b mm 1502 1502
Total height H2 mm 2090 2025 2025 2125 2125 2225 2225
Lifting height H mm 1600 2900 2900 3100 3100 3300 3300
Max height of operations H1 mm 2090 2980 2980 2980 3430 3630 3830
Size of fork 1t mm 1150*100*32
  1.5t mm 1150*100*35
Fork width b1 mm 230*790
Wheelbase Y mm 1133
Turning radius Wa mm 1500
Turning radius Full load mm/s 80
  no-load mm/s 133
The rate of decline Full load mm/s 103
  no-load mm/s 133
Lift motor rating   KW 15
Battery capacity/voltage   Ah/V 120/12
Self-loading (excluding batteries) 1t kg 452 452 452 452 522 522 522 543 552 562
weight 1.5t kg 512 532 512 532 582 582 582 603 612 622
Battery weight kg 27.5
  27.5
